Operating Band

Cat M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85

Cat NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85

GSM/EDGE 850/900/1800/1900MH

Data Transmission

eMTC: Max. 300Kbps (DL), Max. 375Kbps (UL)

NB1: Max. 32Kbps (DL), Max. 70Kbps (UL)

EDGE: Max. 296Kbps (DL), Max. 236.8Kbps (UL)

GPRS: Max. 107Kbps (DL), Max. 85.6Kbps (UL)

GNSS Chipset

MediaTek High Gain GNSS receiver

Paraller GNSS

GPS + Glonass + Galileo + Beidou

Receiver Type

33 tracking/99 acquisitions- channel GNSS receiver

Sensitivity

Cold start: -149 dBm

Tracking: -163 dBm

Position Accuracy (CEP)

Autonomous < 2m

Standalone TTFF

Cold start: <29s

Warm start: <27s

Hot start: 1s

Digital Input

3

Digital Output

2

Configurable Input (Digital / Analog)

3

LTE / GNSS / Bluetooth Antenna

Internal only

Indicator LED

Network and GNSS

FOTA

Yes

BLE

5.0

Waterproof

IP65

Dimensions

102.5mm x 42.5mm x 12mm (4.04" 1.67" 0.47")

Weight

55g (1.94oz)

Backup Battery

Li-Polymer 200 mAh/ 3.7V

Operating Voltage

8V to 60V DC

Operating Temperature

-30°C +80°C (-22°F 176°F)

Storage Temperature

-40°C +85°C (-40°F 185°F)

Transmit Protocol

TCP, UDP, MQTT, SMS

Data Security & Encryption Option

MD5 / AES256

BLE Accessory Support

Yes

Scheduled Timing / Angle / Distance Report

Report position and status at preset intervals

External Power Status Alarm

Report when external power is disconnected

Low Power Alarm

Report when backup battery is low

Speeding Alarm

Report when speed exceed the pre-set value

Towing Alarm

From internal 6-axis accelerometer

Remote Control

Remote output control

Network Signal Jamming Detection

Report network jamming

Data Roaming Control

Avoid additional data consumption

Driving Behavior Monitoring

Aggressive driving behavior detection, e.g. harsh braking and acceleration

Crash Detection

Accident data collection for reconstruction and analysis
